Part-number relationships
| Relationship | Reference family | Number |
|---|---|---|
| Primary Part Number | Mitsubishi safety relay | ME049233 |
| Manufacturer Relay Number | Number printed for the same relay | R8T30171 |
Excavator Spare Parts
ME049233 R8T30171 24V Safety Relay for Mitsubishi S6K Engines
5 product photos · Swipe on mobile, or hover and select a thumbnail.
OEM / referenceME049233
Specification24V Engine Safety Relay
Catalog ID51096711
24V safety relay identified by Mitsubishi part number ME049233 and relay number R8T30171. Exact-number catalog records support Mitsubishi S6K engine applications. Confirm the complete relay label, connector layout and machine wiring diagram before ordering.
- Product Type
- Engine Safety Relay
- Product Brand
- EexcavaStart
- Rated Voltage
- 24V
- Condition
- New replacement part
Send the machine model, engine model or nameplate photo so our team can confirm compatibility before shipment.
Product fitment guide
Part numbers and compatible models
Quickly compare the reference number and recorded machine applications. Use the original photos and the checklist before ordering.
Part identification
Reference numbers
Primary number
Manufacturer number
Formatting aliases are the same number written differently. Related assemblies and remanufactured numbers are not presented as direct interchanges.
Product summary
24V Engine Safety Relay
- Category
- Excavator Spare Parts
- Catalog ID
- 51096711
- Photo views
- 5
Before ordering
Confirm these details
- Match the complete part number on the original component.
- Compare connectors, mounting points and visible dimensions with the product photos.
- Confirm the exact machine or engine model and serial range before ordering.
Machine fitment
Compatible model references
3 model references
Compatibility lists identify searchable model families, not every production serial range. Confirm the original part number and machine serial number before purchase.
Quick fitment answers
Common questions about ME049233
Which machines use ME049233?
Recorded compatible model references include Engine family: Mitsubishi S6K, Catalog-recorded equipment family: Cat 312C / 320C / 330C; confirm by serial number, Fitment limitation: Confirm complete relay label, connector and wiring diagram. Confirm the complete part number and machine serial range before ordering.
What numbers are documented for ME049233?
Manufacturer number: R8T30171.
How do I confirm ME049233 before ordering?
Match the complete part number on the original component. Compare connectors, mounting points and visible dimensions with the product photos. Confirm the exact machine or engine model and serial range before ordering. Send clear photos of the original unit and connector layout when requesting a quote.
