Excavator Spare Parts

803601667 A2B-Z Height Limit Switch for XCMG QY30KA Crane

Name: 803601667 A2B-Z Height Limit Switch for XCMG QY30KA Crane
Brand: EexcavaStart
SKU: 803601667

OEM / reference803601667

SpecificationAnti-Two-Block Height Limit Switch

Catalog ID51296464

Anti-two-block height limit switch documented as XCMG part number 803601667 and switch model A2B-Z. A QY30KA consuming-parts list identifies the exact number and product type, and an XCMG e-commerce record supplies Hirschmann material number 217694. Four owned photographs show one consistent switch and cable assembly. Confirm crane serial and cable length.

Fitment status: Verified · Checked 2026-08-01

Product Type: Anti-two-block / height limit switch
Supply Scope: Switch, cable and connector shown

Send email inquiry Ask on WhatsApp Return to catalog

Send the machine model, engine model or nameplate photo so our team can confirm compatibility before shipment.

Part-number relationships

Relationship	Reference family	Number
Primary Part Number	XCMG crane parts number	803601667
Manufacturer Model	Height-limit switch model	A2B-Z
Manufacturer Material Number	Hirschmann material reference	217694

Fitment data verified. Exact-reference evidence is retained in the protected product audit record · Checked 2026-08-01.

Product fitment guide

Part numbers and compatible models

Quickly compare the reference number and recorded machine applications. Use the original photos and the checklist before ordering.

Part identification

Reference numbers

Primary number

803601667

Manufacturer number

A2B-Z
217694

Formatting aliases are the same number written differently. Related assemblies and remanufactured numbers are not presented as direct interchanges.

Product summary

Anti-Two-Block Height Limit Switch

Category: Excavator Spare Parts
Catalog ID: 51296464
Photo views: 4

Before ordering

Confirm these details

Match the complete part number on the original component.
Compare connectors, mounting points and visible dimensions with the product photos.
Confirm the exact machine or engine model and serial range before ordering.

Machine fitment

Compatible model references

2 model references

XCMG mobile crane: QY30KA
Fitment limitation: Confirm crane serial, cable length and mounting position

Compatibility lists identify searchable model families, not every production serial range. Confirm the original part number and machine serial number before purchase.

Quick fitment answers

Common questions about 803601667

Which machines use 803601667?

Recorded compatible model references include XCMG mobile crane: QY30KA, Fitment limitation: Confirm crane serial, cable length and mounting position. Confirm the complete part number and machine serial range before ordering.

What numbers are documented for 803601667?

Manufacturer number: A2B-Z, 217694.

How do I confirm 803601667 before ordering?

Match the complete part number on the original component. Compare connectors, mounting points and visible dimensions with the product photos. Confirm the exact machine or engine model and serial range before ordering. Send clear photos of the original unit and connector layout when requesting a quote.
