Excavator Starter Motors

36100-41000 24V 5.0kW 11T Starter for Hyundai D4AF D4DB HD65 HD72 HD78

36100-41000 24V 5.0kW 11T Starter for Hyundai D4AF D4DB HD65 HD72 HD78, OEM/reference 36100-41000, 24V / 5.00kW / 11 teeth / clockwise starter motor, product view 1
1 / 2

2 product photos · Swipe on mobile, or hover and select a thumbnail.

OEM / reference36100-41000
Specification24V / 5.00kW / 11 teeth / clockwise starter motor
Catalog ID71201869

Hyundai/Kia starter number 36100-41000, also written 3610041000, is listed in the official replacement catalog as a 24V 5.0kW clockwise starter with an 11-tooth pinion, four mounting holes and two threaded holes. Published applications cover Hyundai HD65 with D4AF, D4AL, D4DB, D4DC or D4DD engines, HD72 with D4DB or D4DC, and HD78 with D4DA from September 2006. Confirm the complete number, 24V system, 11 teeth, flange pattern, terminals and chassis/serial range against the original unit before shipment.

Product Type
Starter Motor
Published Voltage
24 V
Published Rated Power
5.00 kW
Published Rotation
CW - clockwise
Published Pinion Teeth
11
Published Mounting Holes
4
Published Threaded Holes
2
Published Size A
60.00 mm
Published Size B
16.50 mm
Published Overall Length
288.00 mm
Published Terminal Threads
C1/C2 M10 x 1.25
Condition
New replacement part
Send email inquiry Ask on WhatsApp Return to catalog

Send the machine model, engine model or nameplate photo so our team can confirm compatibility before shipment.

Part-number relationships

RelationshipReference familyNumber
Primary Equipment Part NumberHyundai / Kia36100-41000
Same-number Formatting VariantCompact alias3610041000
Official Equipment Catalog Cross-Reference - Verify Complete UnitHyundai / Kia36100-41100
Official Equipment Catalog Cross-Reference - Verify Complete UnitHyundai / Kia36100-45501
Official Equipment Catalog Cross-Reference - Verify Complete UnitHyundai / Kia36100-45900
Official Equipment Catalog Cross-Reference - Verify Complete UnitHyundai / Kia36100-45700
Official Replacement ProductExact replacement catalog lookupS9154
Replacement Catalog Reference - Verify Complete UnitReference catalogUD00647S
Aftermarket Catalog Reference - Verify Complete UnitReference catalog115751
Aftermarket Catalog Reference - Verify Complete UnitReference catalog151.529.113
Aftermarket Catalog Reference - Verify Complete UnitReference catalog220509
Aftermarket Catalog Reference - Verify Complete UnitReference catalog602038
Aftermarket Catalog Reference - Verify Complete UnitReference catalogDRS1263
Aftermarket Catalog Reference - Verify Complete UnitReference catalogSTA3505
Aftermarket Catalog Reference - Verify Complete UnitReference catalogSTR54196
Aftermarket Catalog Reference - Verify Complete UnitReference catalogVAL1251025
Aftermarket Catalog Reference - Verify Complete UnitReference catalogCST32609GS
Aftermarket Catalog Reference - Verify Complete UnitReference catalog20493906OE
Aftermarket Catalog Reference - Verify Complete UnitReference catalog6032609.1
Aftermarket Catalog Reference - Verify Complete UnitReference catalogSTR00166
Aftermarket Catalog Reference - Verify Complete UnitReference catalogF032115751
Aftermarket Catalog Reference - Verify Complete UnitReference catalogAM-2186

Product fitment guide

Part numbers and compatible models

Quickly compare the reference number and recorded machine applications. Use the original photos and the checklist before ordering.

Part identification

Reference numbers

Primary number
  • 36100-41000
Formatting alias
  • 3610041000
Other documented relationship
  • 36100-41100
  • 36100-45501
  • 36100-45900
  • 36100-45700
  • S9154
  • UD00647S
  • 115751
  • 151.529.113
  • 220509
  • 602038
  • DRS1263
  • STA3505
  • STR54196
  • VAL1251025
  • CST32609GS
  • 20493906OE
  • 6032609.1
  • STR00166
  • F032115751
  • AM-2186

Formatting aliases are the same number written differently. Related assemblies and remanufactured numbers are not presented as direct interchanges.

Product summary

24V / 5.00kW / 11 teeth / clockwise starter motor

Category
Excavator Starter Motors
Catalog ID
71201869
Photo views
2

Before ordering

Confirm these details

  • Confirm voltage and power rating against the original starter nameplate.
  • Compare mounting-hole pattern, flange position and overall body orientation.
  • Confirm pinion tooth count and rotation where those values are specified.
  • Verify the engine model and machine serial range before ordering.

Machine fitment

Compatible model references

4 model references

  • Hyundai HD Light HD65: D4AF / D4AL / D4DB / D4DC / D4DD; from 09/2006
  • Hyundai HD Light HD72: D4DB / D4DC; from 09/2006
  • Hyundai HD Light HD78: D4DA; from 09/2006
  • Fitment limitation: Confirm 36100-41000/3610041000, 24 V, 11 teeth, four-hole flange, two threaded holes, terminals and chassis/serial range

Compatibility lists identify searchable model families, not every production serial range. Confirm the original part number and machine serial number before purchase.

Quick fitment answers

Common questions about 36100-41000

Which machines use 36100-41000?

Recorded compatible model references include Hyundai HD Light HD65: D4AF / D4AL / D4DB / D4DC / D4DD; from 09/2006, Hyundai HD Light HD72: D4DB / D4DC; from 09/2006, Hyundai HD Light HD78: D4DA; from 09/2006, Fitment limitation: Confirm 36100-41000/3610041000, 24 V, 11 teeth, four-hole flange, two threaded holes, terminals and chassis/serial range. Confirm the complete part number and machine serial range before ordering.

What numbers are documented for 36100-41000?

Formatting aliases for the same number: 3610041000.

How do I confirm 36100-41000 before ordering?

Confirm voltage and power rating against the original starter nameplate. Compare mounting-hole pattern, flange position and overall body orientation. Confirm pinion tooth count and rotation where those values are specified. Send clear photos of the original unit and connector layout when requesting a quote.
