Alternators

352-4700 24V 150A Replacement Alternator for Caterpillar 320 GC, 320 L, 336 and C4.4/C7.1 Equipment

352-4700 24V 150A Replacement Alternator for Caterpillar 320 GC, 320 L, 336 and C4.4/C7.1 Equipment, OEM/reference 352-4700, Alternator, product view 1
1 / 4

4 product photos · Swipe on mobile, or hover and select a thumbnail.

OEM / reference352-4700
SpecificationAlternator
Catalog ID53242306
Product Type
Replacement alternator
Voltage
24 V
Rated Output
150 A (reviewed replacement configuration)
Rotation
CW
Design Family
IR/IF
Original-Unit Catalog Comparison
145 A; confirm the physical unit
Condition
New replacement part
Send email inquiry Ask on WhatsApp Return to catalog

Send the machine model, engine model or nameplate photo so our team can confirm compatibility before shipment.

Quotation details: MOQ, availability, lead time, item condition (new or remanufactured) and warranty coverage must be confirmed in your quotation before ordering.

Part-number relationships

RelationshipReference familyNumber
Primary Part NumberExact reviewed reference352-4700
Formatted AliasSame reference without punctuation; not a separate interchange3524700
Independent Catalog NumberCatalog cross-reference number; not an OEM number20468N
Cataloged Manufacturer FamilyManufacturer family stated by the official recordBOSCH
Industry Catalog NumberIndependent cross-reference only20468
Cataloged Replacement-Reference FamilyOfficial grouped replacement family; confirm manufacturer context and suffix before substitutionBosch 0 124 655 099, 0 124 655 230, Caterpillar 352-4700, 352470002, Perkins Engine 35 24700

Product fitment guide

Part numbers and compatible models

Quickly compare the reference number and recorded machine applications. Use the original photos and the checklist before ordering.

Part identification

Reference numbers

Primary number
  • 352-4700
Manufacturer number
  • BOSCH
Formatting alias
  • 3524700
Other documented relationship
  • 20468N
  • 20468
  • Bosch 0 124 655 099, 0 124 655 230, Caterpillar 352-4700, 352470002, Perkins Engine 35 24700

Formatting aliases are the same number written differently. Cross-references require a specification and fitment check; they do not by themselves confirm direct interchangeability. Related assemblies and remanufactured numbers are separate relationship types.

Product summary

Alternator

Category
Alternators
Catalog ID
53242306
Photo views
4

Before ordering

Confirm these details

  • Confirm voltage and rated amperage against the original alternator label.
  • Compare mounting ears, pulley type and pulley-groove count.
  • Check plug shape, terminal position and regulator connection.
  • Verify the engine model and machine serial range before ordering.

Machine fitment

Compatible model references

8 model references

  • Caterpillar published applications — group 1: 140 (1975-1996) — L6 10.5L 10455cc 638cid 3306; L6 10.5L 10455cc 638cid Caterpillar 3306 / 320 GC (2017-2024) — L4 4.4L 269cid Caterpillar C4.4 / 320 L (2017-2024) — L4 4.4L 269cid C4.4; L4 4.4L 269cid Caterpillar C4.4; L6 7.0L 428cid Caterpillar C7.1 / 320 (1991-2000, 2017-2024) — L6 7.0L 428cid C7.1; L6 7.0L 428cid Caterpillar C7.1; L4 4.4L 269cid Caterpillar C4.4 / 320D2 GC (2006-2021) — L6 7.0L 428cid C7.1; L6 7.0L 428cid Caterpillar C7.1 / 320D2 L (2006-2021) — L6 7.0L 428cid C7.1; L6 7.0L 428cid Caterpillar C7.1 / 320D2 (2006-2021) — L6 7.0L 428cid C7.1; L6 7.0L 428cid Caterpillar C7.1 / 320G C (2018-2024) — L4 4.4L 269cid C4.4; L4 4.4L 269cid Caterpillar C4.4
  • Caterpillar published applications — group 2: 323 (2017-2024) — L6 7.0L 428cid C7.1; L6 7.0L 428cid Caterpillar C7.1 / 323D2 L (2017-2022) — L6 7.0L 428cid Caterpillar C7.1 / 323D2 (2017-2022) — L6 7.0L 428cid Caterpillar C7.1 / 336 (2008-2013, 2017-2024) — L6 15.2L 928cid C15; L6 15.2L 928cid Caterpillar C15; L6 8.8L 537cid Caterpillar C9; L6 9.3L 567cid Caterpillar C9.3; L6 9.3L 567cid Caterpillar C9.3B / 340 (2019-2024) — L6 9.3L 567cid C9.3B; L6 9.3L 567cid Caterpillar C9.3B / 350 (2019-2024) — L6 9.3L 567cid C9.3B; L6 9.3L 567cid Caterpillar C9.3B / 621H (2012-2024) — L6 12.5L 763cid Caterpillar C13 / 621K (2014-2024) — L6 12.5L 763cid Caterpillar C13
  • Caterpillar published applications — group 3: 623H (2012-2024) — L6 12.5L 763cid Caterpillar C13 / 623K LRC (2014-2024) — L6 12.5L 763cid Caterpillar C13 / 623K (2014-2024) — L6 12.5L 763cid Caterpillar C13 / 627H (2012-2024) — L6 12.5L 763cid Caterpillar C13 / 730C (2015-2018) — L6 18.1L 18099cc 1105cid C18; L6 18.1L 18099cc 1105cid Caterpillar C18 / 735 (2006-2024) — L6 12.5L 763cid C13; L6 12.5L 763cid Caterpillar C13 / 735B (2011-2015) — L6 15.2L 928cid C15; L6 15.2L 928cid Caterpillar C15 / 735C (2015-2019) — L6 12.5L 763cid Caterpillar C13; L6 15.2L 928cid Caterpillar C15
  • Caterpillar published applications — group 4: 740 (2002-2014) — L6 15.2L 928cid C15; L6 15.2L 928cid Caterpillar C15 / 740B (2011-2015) — L6 15.2L 928cid C15; L6 15.2L 928cid Caterpillar C15 / 740C EJ (2015-2018) — L6 18.1L 1105cid Caterpillar C18 / 740C (2015-2018) — L6 18.1L 1105cid Caterpillar C18 / 745 (2017-2019) — L6 18.1L 18099cc 1105cid C18; L6 18.1L 18099cc 1105cid Caterpillar C18 / 745C (2015-2019) — L6 18.1L 1105cid Caterpillar C18 / 770G (2014-2019) — L6 15.2L 928cid C15; L6 15.2L 928cid Caterpillar C15 / 772G (2014-2024) — L6 18.1L 18099cc 1105cid C18; L6 18.1L 18099cc 1105cid Caterpillar C18
  • Caterpillar published applications — group 5: 773G LCR (2012-2019) — V12 27.0L 1650cid C27; V12 27.0L 1650cid Caterpillar C27 / 775G (2012-2019) — V12 27.0L 1650cid Caterpillar C27 / 777E (2016-2024) — V12 32.1L 1959cid Caterpillar C32 / 777G (2012-2022) — V12 32.1L 1959cid Caterpillar C32 / 924K (2012-2024) — L6 7.0L 428cid Caterpillar C7.1 / 926M (2013-2024) — L6 7.0L 428cid Caterpillar C7.1 / 930M (2015-2024) — L6 7.0L 428cid Caterpillar C7.1 / 938K (2012-2024) — L6 7.0L 428cid Caterpillar C7.1
  • Caterpillar published applications — group 6: 938M (2013-2020) — L6 7.0L 428cid Caterpillar C7.1 / 950GC (2017-2024) — L6 7.0L 428cid Caterpillar C7.1 / 950K (2012-2015) — L6 7.0L 428cid Caterpillar C7.1 / 950M Z (2021-2024) — L6 7.0L 428cid Caterpillar C7.1 / 950M (2014-2024, 2015-2024) — L6 7.2L 441cid Caterpillar C7; L6 12.5L 763cid Caterpillar C13 / 962K (2012-2015) — L6 7.0L 428cid Caterpillar C7.1 / 962M Z (2015-2024) — L6 7.0L 428cid Caterpillar C7.1 / 962M (2013-2024, 2014-2024) — L6 7.2L 441cid Caterpillar C7; L6 7.0L 428cid Caterpillar C7.1
  • Caterpillar published applications — group 7: 966M XE (2013-2022) — L6 9.3L 567cid Caterpillar C9.3 / 966M (2013-2024) — L6 9.3L 567cid Caterpillar C9.3 / 972L (2018-2024) — L6 9.3L 567cid Caterpillar C9.3 / 972M XE (2014-2024) — L6 9.3L 567cid Caterpillar C9.3 / 972M (2014-2024) — L6 9.3L 567cid Caterpillar C9.3 / 980M (2014-2024) — L6 12.5L 763cid Caterpillar C13 / 982M (2014-2024) — L6 12.5L 763cid Caterpillar C13 / 986K (2017-2024) — L6 15.2L 928cid Caterpillar C15
  • Caterpillar published applications — group 8: AP1000F (2019-2024) — L6 7.0L 428cid Caterpillar C7.1 / D5R LGP (1996-2009) — L6 6.6L 403cid C6.6; L6 6.6L 403cid Caterpillar C6.6 / D5R XL (1996-2009) — L6 6.6L 403cid C6.6; L6 6.6L 403cid Caterpillar C6.6

Fitment / evidence notes

  • Fitment limitation: Confirm the complete part number, electrical rating, rotation, drive or pulley, mounting, terminals and equipment serial range before ordering.

Compatibility lists identify searchable model families, not every production serial range. Confirm the original part number and machine serial number before purchase.

Quick fitment answers

Common questions about 352-4700

Which machines use 352-4700?

Recorded compatible model references include Caterpillar published applications — group 1: 140 (1975-1996) — L6 10.5L 10455cc 638cid 3306; L6 10.5L 10455cc 638cid Caterpillar 3306 / 320 GC (2017-2024) — L4 4.4L 269cid Caterpillar C4.4 / 320 L (2017-2024) — L4 4.4L 269cid C4.4; L4 4.4L 269cid Caterpillar C4.4; L6 7.0L 428cid Caterpillar C7.1 / 320 (1991-2000, 2017-2024) — L6 7.0L 428cid C7.1; L6 7.0L 428cid Caterpillar C7.1; L4 4.4L 269cid Caterpillar C4.4 / 320D2 GC (2006-2021) — L6 7.0L 428cid C7.1; L6 7.0L 428cid Caterpillar C7.1 / 320D2 L (2006-2021) — L6 7.0L 428cid C7.1; L6 7.0L 428cid Caterpillar C7.1 / 320D2 (2006-2021) — L6 7.0L 428cid C7.1; L6 7.0L 428cid Caterpillar C7.1 / 320G C (2018-2024) — L4 4.4L 269cid C4.4; L4 4.4L 269cid Caterpillar C4.4, Caterpillar published applications — group 2: 323 (2017-2024) — L6 7.0L 428cid C7.1; L6 7.0L 428cid Caterpillar C7.1 / 323D2 L (2017-2022) — L6 7.0L 428cid Caterpillar C7.1 / 323D2 (2017-2022) — L6 7.0L 428cid Caterpillar C7.1 / 336 (2008-2013, 2017-2024) — L6 15.2L 928cid C15; L6 15.2L 928cid Caterpillar C15; L6 8.8L 537cid Caterpillar C9; L6 9.3L 567cid Caterpillar C9.3; L6 9.3L 567cid Caterpillar C9.3B / 340 (2019-2024) — L6 9.3L 567cid C9.3B; L6 9.3L 567cid Caterpillar C9.3B / 350 (2019-2024) — L6 9.3L 567cid C9.3B; L6 9.3L 567cid Caterpillar C9.3B / 621H (2012-2024) — L6 12.5L 763cid Caterpillar C13 / 621K (2014-2024) — L6 12.5L 763cid Caterpillar C13, Caterpillar published applications — group 3: 623H (2012-2024) — L6 12.5L 763cid Caterpillar C13 / 623K LRC (2014-2024) — L6 12.5L 763cid Caterpillar C13 / 623K (2014-2024) — L6 12.5L 763cid Caterpillar C13 / 627H (2012-2024) — L6 12.5L 763cid Caterpillar C13 / 730C (2015-2018) — L6 18.1L 18099cc 1105cid C18; L6 18.1L 18099cc 1105cid Caterpillar C18 / 735 (2006-2024) — L6 12.5L 763cid C13; L6 12.5L 763cid Caterpillar C13 / 735B (2011-2015) — L6 15.2L 928cid C15; L6 15.2L 928cid Caterpillar C15 / 735C (2015-2019) — L6 12.5L 763cid Caterpillar C13; L6 15.2L 928cid Caterpillar C15, Caterpillar published applications — group 4: 740 (2002-2014) — L6 15.2L 928cid C15; L6 15.2L 928cid Caterpillar C15 / 740B (2011-2015) — L6 15.2L 928cid C15; L6 15.2L 928cid Caterpillar C15 / 740C EJ (2015-2018) — L6 18.1L 1105cid Caterpillar C18 / 740C (2015-2018) — L6 18.1L 1105cid Caterpillar C18 / 745 (2017-2019) — L6 18.1L 18099cc 1105cid C18; L6 18.1L 18099cc 1105cid Caterpillar C18 / 745C (2015-2019) — L6 18.1L 1105cid Caterpillar C18 / 770G (2014-2019) — L6 15.2L 928cid C15; L6 15.2L 928cid Caterpillar C15 / 772G (2014-2024) — L6 18.1L 18099cc 1105cid C18; L6 18.1L 18099cc 1105cid Caterpillar C18, Caterpillar published applications — group 5: 773G LCR (2012-2019) — V12 27.0L 1650cid C27; V12 27.0L 1650cid Caterpillar C27 / 775G (2012-2019) — V12 27.0L 1650cid Caterpillar C27 / 777E (2016-2024) — V12 32.1L 1959cid Caterpillar C32 / 777G (2012-2022) — V12 32.1L 1959cid Caterpillar C32 / 924K (2012-2024) — L6 7.0L 428cid Caterpillar C7.1 / 926M (2013-2024) — L6 7.0L 428cid Caterpillar C7.1 / 930M (2015-2024) — L6 7.0L 428cid Caterpillar C7.1 / 938K (2012-2024) — L6 7.0L 428cid Caterpillar C7.1, Caterpillar published applications — group 6: 938M (2013-2020) — L6 7.0L 428cid Caterpillar C7.1 / 950GC (2017-2024) — L6 7.0L 428cid Caterpillar C7.1 / 950K (2012-2015) — L6 7.0L 428cid Caterpillar C7.1 / 950M Z (2021-2024) — L6 7.0L 428cid Caterpillar C7.1 / 950M (2014-2024, 2015-2024) — L6 7.2L 441cid Caterpillar C7; L6 12.5L 763cid Caterpillar C13 / 962K (2012-2015) — L6 7.0L 428cid Caterpillar C7.1 / 962M Z (2015-2024) — L6 7.0L 428cid Caterpillar C7.1 / 962M (2013-2024, 2014-2024) — L6 7.2L 441cid Caterpillar C7; L6 7.0L 428cid Caterpillar C7.1, Caterpillar published applications — group 7: 966M XE (2013-2022) — L6 9.3L 567cid Caterpillar C9.3 / 966M (2013-2024) — L6 9.3L 567cid Caterpillar C9.3 / 972L (2018-2024) — L6 9.3L 567cid Caterpillar C9.3 / 972M XE (2014-2024) — L6 9.3L 567cid Caterpillar C9.3 / 972M (2014-2024) — L6 9.3L 567cid Caterpillar C9.3 / 980M (2014-2024) — L6 12.5L 763cid Caterpillar C13 / 982M (2014-2024) — L6 12.5L 763cid Caterpillar C13 / 986K (2017-2024) — L6 15.2L 928cid Caterpillar C15, Caterpillar published applications — group 8: AP1000F (2019-2024) — L6 7.0L 428cid Caterpillar C7.1 / D5R LGP (1996-2009) — L6 6.6L 403cid C6.6; L6 6.6L 403cid Caterpillar C6.6 / D5R XL (1996-2009) — L6 6.6L 403cid C6.6; L6 6.6L 403cid Caterpillar C6.6. Recorded fitment/evidence notes: Fitment limitation: Confirm the complete part number, electrical rating, rotation, drive or pulley, mounting, terminals and equipment serial range before ordering. Confirm the complete part number and machine serial range before ordering.

What numbers are documented for 352-4700?

Manufacturer number: BOSCH. Formatting aliases for the same number: 3524700.

How do I confirm 352-4700 before ordering?

Confirm voltage and rated amperage against the original alternator label. Compare mounting ears, pulley type and pulley-groove count. Check plug shape, terminal position and regulator connection. Send clear photos of the original unit and connector layout when requesting a quote.
