320/09022 12V 4.2kW 11-Tooth Starter for JCB 3CX, 4CX and Telehandlers

Name: 320/09022 12V 4.2kW 11-Tooth Starter for JCB 3CX, 4CX and Telehandlers
Brand: EexcavaStart
SKU: 320/09022

1 / 4

4 product photos · Swipe on mobile, or hover and select a thumbnail.

OEM / reference320/09022

SpecificationStarter Motor

Catalog ID89370260

320/09022 is a JCB starter reference in the official WAI 30230N replacement family. WAI specifies a new 12-volt, 4.2 kW, clockwise, 11-tooth Letrika/Iskra PLGR starter. Published applications include JCB 2CX, 3CX, 3DX and 4CX backhoe loaders, multiple 500-series telehandlers, wheel loaders, skid-steer loaders and forklifts using JCB 444, DieselMax, EcoMax or Perkins 1004/1104 engine families. Confirm the complete number, rating, 11-tooth drive, flange, terminals and machine serial range.

Product Type: PLGR starter motor
Voltage: 12V
Rated Power: 4.2 kW
Pinion Teeth: 11
Rotation: Clockwise (CW)
Design Family: Letrika / Iskra PLGR
Condition: New replacement part

Send email inquiry Ask on WhatsApp Return to catalog

Send the machine model, engine model or nameplate photo so our team can confirm compatibility before shipment.

Part-number relationships

Relationship	Reference family	Number
Primary JCB Part Number	Official WAI replacement-reference entry	320/09022
Formatted Alias	Same JCB number without slash; not a separate interchange	32009022
JCB Replacement Reference Family	Cataloged replacement references	320/09026 / 320/09032 / 320/09035 / 320/09144 / 320/09346 / 320/09409 / 320/09452 / 320/09454
Letrika / Iskra Manufacturer References	Cataloged manufacturer references	11.131.292 / 11.131.697 / 11.131.711 / 11.131.848 / 11.132.113 / IS1105 / AZF4181 / AZF4186 / AZF4224 / AZF4301 / AZF4576
Mahle Reference	Cataloged manufacturer reference	MS 84
Aftermarket Catalog Number	Official WAI product record	WAI 30230N

Product fitment guide

Part numbers and compatible models

Quickly compare the reference number and recorded machine applications. Use the original photos and the checklist before ordering.

Part identification

Reference numbers

Primary number

320/09022

Manufacturer number

11.131.292 / 11.131.697 / 11.131.711 / 11.131.848 / 11.132.113 / IS1105 / AZF4181 / AZF4186 / AZF4224 / AZF4301 / AZF4576

Formatting alias

32009022

Other documented relationship

320/09026 / 320/09032 / 320/09035 / 320/09144 / 320/09346 / 320/09409 / 320/09452 / 320/09454
MS 84
WAI 30230N

Formatting aliases are the same number written differently. Related assemblies and remanufactured numbers are not presented as direct interchanges.

Product summary

Starter Motor

Category: Excavator Starter Motors
Catalog ID: 89370260
Photo views: 4

Before ordering

Confirm these details

Confirm voltage and power rating against the original starter nameplate.
Compare mounting-hole pattern, flange position and overall body orientation.
Confirm pinion tooth count and rotation where those values are specified.
Verify the engine model and machine serial range before ordering.

Machine fitment

Compatible model references

5 model references

JCB Backhoe Loaders: 2CX / 3CX / 3DX / 4CX
JCB Telehandler Examples: 524-50 / 526-56 / 531-70 / 533-105 / 535-95 / 535-125 / 535-140 / 536-60 / 540-140 / 540-170 / 541-70 / 550-140 / 550-170
Additional JCB Equipment: 110 series / Robot and skid-steer loaders / 411-416 loaders / 926-940 forklifts / VM115 rollers
Published Engine Families: JCB 444 / DieselMax / EcoMax and Perkins 1004C-44TA / 1104C-44, depending on machine
Fitment Limitation: Confirm 320/09022, 12V/4.2kW label, 11-tooth pinion, flange, terminals and serial range

Compatibility lists identify searchable model families, not every production serial range. Confirm the original part number and machine serial number before purchase.

Quick fitment answers

Common questions about 320/09022

Which machines use 320/09022?

Recorded compatible model references include JCB Backhoe Loaders: 2CX / 3CX / 3DX / 4CX, JCB Telehandler Examples: 524-50 / 526-56 / 531-70 / 533-105 / 535-95 / 535-125 / 535-140 / 536-60 / 540-140 / 540-170 / 541-70 / 550-140 / 550-170, Additional JCB Equipment: 110 series / Robot and skid-steer loaders / 411-416 loaders / 926-940 forklifts / VM115 rollers, Published Engine Families: JCB 444 / DieselMax / EcoMax and Perkins 1004C-44TA / 1104C-44, depending on machine, Fitment Limitation: Confirm 320/09022, 12V/4.2kW label, 11-tooth pinion, flange, terminals and serial range. Confirm the complete part number and machine serial range before ordering.

What numbers are documented for 320/09022?

Manufacturer number: 11.131.292 / 11.131.697 / 11.131.711 / 11.131.848 / 11.132.113 / IS1105 / AZF4181 / AZF4186 / AZF4224 / AZF4301 / AZF4576. Formatting aliases for the same number: 32009022.

How do I confirm 320/09022 before ordering?

Confirm voltage and power rating against the original starter nameplate. Compare mounting-hole pattern, flange position and overall body orientation. Confirm pinion tooth count and rotation where those values are specified. Send clear photos of the original unit and connector layout when requesting a quote.
