19011194 24V 75A Alternator for Caterpillar 143H, 14H and 163H

Q: What numbers are documented for 19011194?

Primary Part Number: 19011194. Independent Catalog Number: 8569N. Cataloged Manufacturer Family: DELCO. Industry Catalog Number: 8569. Cataloged Replacement-Reference Family: Delco 10459355, 19011194. Relationship labels distinguish formatting aliases, direct interchanges, remanufactured references and related assemblies.

Q: How do I confirm 19011194 before ordering?

Match the complete part number, compare the connector or mounting arrangement with the product photos, and confirm the machine or engine model and serial range. Send clear photos of the original unit when requesting a quote.

19011194 24V 75A Alternator for Caterpillar 143H, 14H and 163H, OEM/reference 19011194, Alternator, product view 1

1 / 2

2 product photos · Swipe on mobile, or hover and select a thumbnail.

OEM / reference19011194

SpecificationAlternator

Catalog ID78232973

19011194 is an exact product reference in the reviewed official electrical catalog. The catalog specifies 24V, 75A, BI, IR/EF for selected Caterpillar 143H, 14H, 163H applications. Compare the complete reference, electrical label, mounting, terminals, drive or pulley and the retained EexcavaStart product photographs with the original unit before ordering.

Product Type: Alternator
Voltage: 24 V
Rated Output: 75 A
Rotation: BI
Design Family: IR/EF
Manufacturer Series: 34SI
Pulley Class: W/O PULLEY
Condition: New replacement part

Send email inquiry Ask on WhatsApp Return to catalog

Send the machine model, engine model or nameplate photo so our team can confirm compatibility before shipment.

Part-number relationships

Relationship	Reference family	Number
Primary Part Number	Exact reviewed reference	19011194
Independent Catalog Number	Catalog cross-reference number; not an OEM number	8569N
Cataloged Manufacturer Family	Manufacturer family stated by the official record	DELCO
Industry Catalog Number	Independent cross-reference only	8569
Cataloged Replacement-Reference Family	Official grouped replacement family; confirm manufacturer context and suffix before substitution	Delco 10459355, 19011194

Product fitment guide

Part numbers and compatible models

Quickly compare the reference number and recorded machine applications. Use the original photos and the checklist before ordering.

Part identification

Reference numbers

Primary number

19011194

Manufacturer number

DELCO

Other documented relationship

8569N
8569
Delco 10459355, 19011194

Formatting aliases are the same number written differently. Related assemblies and remanufactured numbers are not presented as direct interchanges.

Product summary

Alternator

Category: Excavator Alternators
Catalog ID: 78232973
Photo views: 2

Before ordering

Confirm these details

Confirm voltage and rated amperage against the original alternator label.
Compare mounting ears, pulley type and pulley-groove count.
Check plug shape, terminal position and regulator connection.
Verify the engine model and machine serial range before ordering.

Machine fitment

Compatible model references

3 model references

Caterpillar published applications — group 1: 143H (2000-2007) — L6 10.3L 629cid Caterpillar / 14H (1996-2007) — L6 10.3L 629cid Caterpillar / 163H (2000-2007) — L6 10.3L 629cid Caterpillar / 16H (2004-2008) — L6 12.0L 732cid Caterpillar / 385B (2002-2004) — L6 15.0L 893cid Caterpillar / 5090B (2002-2004) — L6 15.0L 893cid Caterpillar / 621B2 (2000) — L6 14.6L 893cid Caterpillar / 631E (1985-2000) — V8 18.0L 1099cid Caterpillar
Caterpillar published applications — group 2: 633D (1986-1991) — L6 14.6L 893cid Caterpillar / 725 (2001-2015) — L6 10.3L 629cid Caterpillar; L6 11.1L 677cid Caterpillar / 735B (2006-2015) — L6 14.6L 893cid Caterpillar / 740B (2006-2015) — L6 14.6L 893cid Caterpillar
Fitment limitation: Confirm the complete part number, electrical rating, rotation, drive or pulley, mounting, terminals and equipment serial range before ordering.

Compatibility lists identify searchable model families, not every production serial range. Confirm the original part number and machine serial number before purchase.

Quick fitment answers

Common questions about 19011194

Which machines use 19011194?

Recorded compatible model references include Caterpillar published applications — group 1: 143H (2000-2007) — L6 10.3L 629cid Caterpillar / 14H (1996-2007) — L6 10.3L 629cid Caterpillar / 163H (2000-2007) — L6 10.3L 629cid Caterpillar / 16H (2004-2008) — L6 12.0L 732cid Caterpillar / 385B (2002-2004) — L6 15.0L 893cid Caterpillar / 5090B (2002-2004) — L6 15.0L 893cid Caterpillar / 621B2 (2000) — L6 14.6L 893cid Caterpillar / 631E (1985-2000) — V8 18.0L 1099cid Caterpillar, Caterpillar published applications — group 2: 633D (1986-1991) — L6 14.6L 893cid Caterpillar / 725 (2001-2015) — L6 10.3L 629cid Caterpillar; L6 11.1L 677cid Caterpillar / 735B (2006-2015) — L6 14.6L 893cid Caterpillar / 740B (2006-2015) — L6 14.6L 893cid Caterpillar, Fitment limitation: Confirm the complete part number, electrical rating, rotation, drive or pulley, mounting, terminals and equipment serial range before ordering.. Confirm the complete part number and machine serial range before ordering.

What numbers are documented for 19011194?

Manufacturer number: DELCO.

How do I confirm 19011194 before ordering?

Confirm voltage and rated amperage against the original alternator label. Compare mounting ears, pulley type and pulley-groove count. Check plug shape, terminal position and regulator connection. Send clear photos of the original unit and connector layout when requesting a quote.
